Outdoor RFID Reader Portable , RFID Long Distance Reader For School Management

SUNSHINE RFID Technology Co.,Limited
Contact Now

Outdoor RFID Reader Portable , RFID Long Distance Reader For School Management

Brand Name : SUNSHINE

Model Number : F3421

Certification : CE,ROSH

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T,Western Union

Packaging Details : Carton

Identify direction : Directional

Antenna : 15dBi build-in antenna

RF power range : -30dBm~0.0dBm( adjusted by 32 grade)

Modulation : GFSK

Reading range : 80~120m adjustable RSSI reader can be adjusted less than 10m

Operating frequency : 2.4GHz~2.5GHz ISM

Contact Now

Long Distance UHF Directional 2.45GHz Active RFID Reader For school management

Product Description

  • RS232,RS485,USB,Wiegand26/34/42/50,RJ45, which can realize a reading distance of 80-120m. It owns a superior multi-tags reading rate and can achieve a tag identification rate of 1000 tags/s or above.
  • Build-in 15dbi antenna
  • F3421 is a high-performance 2.45GHz active RFID reader/writer designed for high challenging RFID application environment.

Specifications

  • Self-development communication protocol and can customize and expand as your requirement
  • Compatible to other tag protocol and improve the performance of system application
  • Frequency: 2.45GHz Active RFID reader
  • Long distance identification, strong receiving sensitivity
  • Excellent anti-collision performance
  • Little RF Power (No more than 1dBm, transmitting power ≤2mw), which is suitable for human carry and environment friendly Multiple communication interfaces, also can be customized

Product Electrical Parameters

Operating frequency 2.4GHz~2.5GHz ISM
Identify direction Directional
Antenna 15dBi build-in antenna
RF power range -30dBm~0.0dBm( adjusted by 32 grade)
Receiving sensitivity -90.0dBm
Operating mode FHSS or fixed frequency(set by software)
Modulation GFSK
Reading range

80~120m adjustable

RSSI reader can be adjusted less than 10m

Anti-collision Up to 800-1000 tags read simultaneously
Buffer capacity 2000 tags data
Communication speed 25Kbps, 1Mbps, 2Mbps(adjustable)
Communication interface RS-232, S-485, Ethernet, Wiegand26/34/42/50
Input and output 1 triggering input, 1 relay output
Optional function 2 relays, CAN, RSSI, ID match function, Offline function, Time function
Power supply

AC input: 100~240V, 50/60Hz 1.2A

DC output: 5V/1A

Product size 225mm*225mm*100mm
Packing size 450mm*300mm*140mm
Gross weight 2.78kg
Net weight 1.82kg
Working temperature -20°C~+70°C(-4~+158 degree F)
Storage temperature -40°C~+85°C (-40~+185 degree F)
Accessories Power adapter, Power cable, RS-232 cable, Mounting bracket
Working status indication

Buzzer

Outdoor RFID Reader Portable , RFID Long Distance Reader For School Management

FAQ

Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF

Q4. How about your delivery time?
A: Generally, it will take 3-7 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
